Single-phase Smart Energy Meter Test Bench
HL1000
Single-phase Smart Energy Meter Test Bench
Used for verifying single-phase intelligent energy meters that comply
with the specifications of China Southern Power Grid
Supports IR46-related & special waveform testing
Conducts voltage/frequency influence quantity
Sets/measures 2-41 harmonics & detects distortion
Used for verifying single-phase intelligent energy meters that comply
with the specifications of China Southern Power Grid
Supports IR46-related & special waveform testing
Conducts voltage/frequency influence quantity
Sets/measures 2-41 harmonics & detects distortion
/
Single-phase Smart Energy Meter Test Bench HL1000
Features
-
RS485, infrared, carrier wave, Bluetooth -
Metering accuracy, rate period measurement, demand metering -
Timing function, load recording -
Impact measurement and cost control functions
Highlights
Functions:
- Supports IR46-related & special waveform testing
-
Conducts voltage/frequency influence quantity
-
Sets/measures 2-41 harmonics & detects distortion
-
Verifies multi-spec meters (different grades/con-stants) simultaneously
-
Hierarchical evaluation: initial error, timing errorrepeatability error
-
Layered influence analysis: frequency/volt-age/harmonics/error consistency
Functions:
- Supports IR46-related & special waveform testing
- Conducts voltage/frequency influence quantity
- Sets/measures 2-41 harmonics & detects distortion
- Verifies multi-spec meters (different grades/con-stants) simultaneously
- Hierarchical evaluation: initial error, timing errorrepeatability error
- Layered influence analysis: frequency/volt-age/harmonics/error consistency
Specifications
-
Voltage and current range
Output voltage 57.7V～264V Output current range 0.01A～120A Output power stability ≤ 0.02%/120s (Tested under linear load conditions) Output voltage and current waveform distortion ≤ 0.5% -
Harmonic setting
Harmonic order 2~64times Harmonic content Meet the requirements of IR46 -
Other indicators
Number of meter positions 24, 48, 96 meter positions, etc. Power supply 3X220/380V±10%，50Hz±5%
