12 Ports Fixed UHF RFID Reader HL7206C12

12 Ports Fixed UHF RFID Reader HL7206C12

HL7206C12  is new designed fixed UHF RFID reader with 12 ports for antennas. With Impinj R2000 chispet, support multiple tags reading up to 500 times/second, 0-15 meters long range reading. Widely use for asset management, inventory/warehouse management, vehicle ETC management etc.
  • Item NO.:

    HL7206C12
Products Details
Features
  • Impinj Indy R2000 chipset brings strong prime mover
  • Aluminum casting housing applies to industrial scenarios
  • Various communication / software interfaces match various applications
  • Different developing languages SDK meet different developer needs
  • Excellent communication protocol architecture supports faster data processing algorithm
  • Split-type design supports max date collection range, helping cost saving
  • Special applications customized interfaces / data transferring expandable
  • Seamlessly compatible with RFID middleware for rapid implementation of large projects
  • Widely used in Smart cabinet, documents / tools management, bank assets tracking, Smart retail

UHF RFID READER

RFID reader



Parameters

Hardware, OS and Firmware Management

Processor

ARM9, 400MHz

Memory

Flash 128MB; DRAM 32 MB

Operating System

Linux 2.6

Firmware Upgrade

Demo software / Telnet

API Support

Windows – .NET, C++ and Java SDK
Android - Java
Linux platform – C and Java SDK

Physical Characteristics

Dimensions

260mm(L)*134mm(W)*44mm(H)

Weight

1.3Kgs

HousingMaterial

Die-cast aluminum

Visual Status Indicators

Power, Status, Antenna port indicator

RFID Characteristics

Air Protocols

ISO/ IEC18000-6B,6C / EPC C1Gen2

Chipset

Impinj Indy R2000

Frequency

USA: 902 MHz-928MHz (FCC part 15)

EU: 865-868MHz (ETSI EN 302208)

CN: 920-925MHz (CMIIT)

Supportable /optional

Russian / Japan / Korea /

Malaysia / Thailand / other customizable

Programing Functions

Automatic reading/ White list

Breakpoint Resume / Match reading / Data filter

Data format customizable (PLC / Modbus compatible)

RF Micron / EM Temperature sensor custom Services

Output Power

0dBm-33dBm (±1dBm) adjustable

Channel bandwidth

<200KHz

Reading Distance

0-20m (According to Tag & Environment)

Anti-collision

RSSI / multi-tag / intensive inventory supportable

Work Mode

Fixed / hop frequency optional

Connectivity

Antenna Ports

12* SMA-K / female ports, circular or linear polarization; near and far field compatible

Communications

RJ45, RS-232, RS-485, USB Host & Client, Wiegand

General Purpose I/O

4 inputs (DC 0~24V), 4 outputs (DC_MAX:30V,2A; AC_MAX:125V,0.3A), optically isolated

External WIFI / 4G

Power supply

DC 24V/2.5A (DC 9V ~ 30V,30W)

Environmental

Operating Temp.

-20 - +70°C

Storage Temp.

-40 - +85°C

Humidity

5-90% non-condensing (+25℃)

Sealing

IP5X standard, IP65 sealing after protective casing

Applications
    • File/Documents Management
    • Warehouse Management System
    • Industry 4.0 Smart Manufacturing
    • Warehouse forklift Management
    • IT Asset Inventory Management
