4 Ports Long Range UHF RFID Reader CL7206C4

4 Ports Long Range UHF RFID Reader CL7206C4

CL7206C4 is new designed fixed UHF RFID reader with 4 port for antennas. support multiple tags reading up to 500 times/second. Widely use for asset management, inventory/warehouse management, vehicle ETC management etc.

Product Features

12m long reading handheldLinux 2.6 12m long reading handheldRead Range: 20m
1.2m Drop Proof 12m long reading handheldImpinj R2000
12m long reading handheldRJ45, RS-232, RS-485, USB Host & Client, Wiegand
  • Item NO.:

    CL7206C4
  • Frequency:

    FCC, ETSI, CN, RU, KC optional
  • Air Protocols:

    ISO / IEC18000-6B,6C / EPC C1Gen2, C2GEN2 optional
Products Details
Features
  • Impinj Indy R2000 chipset brings strong prime mover
  • Aluminum casting housing applies to industrial scenarios
  • Various communication / software interfaces match various applications
  • Different developing languages SDK meet different developer needs
  • Excellent communication protocol architecture support faster data processing algorithm
  • Split-type design supports max data collection range, helping cost saving.
  • Special applications customized interfaces / data transferring prolongable
  • Seamlessly compatible with RFID middleware for rapid implementation of large projects
  • Widely used in ITS / ETC , warehousing & logistic, production automation, Smart retail

4 Ports Long Range UHF RFID Reader

4 Ports Long Range UHF RFID Reader

Parameters

Hardware, OS and Firmware Management

Processor

ARM9, 400MHz

Memory

Flash 128MB; DRAM 32 MB

Operating System

Linux 2.6

Firmware Upgrade

Demo software / Telnet

API Support

Windows – .NET, C++ and Java SDK
Android - Java
Linux platform – C and Java SDK

Physical Characteristics

Dimensions

256mm(L)*147.6mm(W)*43.47mm(H)

Weight

1.41Kgs

Housing Material

Die-cast aluminum

Visual Status Indicators

Power, Status, Antenna port indicator

RFID Characteristics

Air Protocols

ISO / IEC18000-6B,6C / EPC C1Gen2, C2GEN2 optional

Chipset

Impinj Indy R2000

Frequency

USA: 902 MHz-928MHz (FCC part 15)

EU: 865-868MHz (ETSI EN 302208)

CN: 920-925MHz (CMIIT)

Supportable /optional

Russian / Japan / Korea /

Malaysia / Thailand / other customizable

Programing Functions

Automatic reading/ White list

Breakpoint Resume / Match reading / Data filter

Data format customizable (PLC / Modbus compatible)

RF Micron / EM Temperature sensor custom Services

Output Power

0dBm-33dBm (±1dBm) adjustable

Channel bandwidth

<200KHz

Reading Distance

0-20m (According to Tag & Environment)

Anti-collision

RSSI / multi-tag / intensive inventory supportable

Work Mode

Fixed / hop frequency optional

Connectivity

Antenna Ports

4 Reverse Polarity TNC ports; circular or linear polarization; near and far field compatible

Communications

RJ45, RS-232, RS-485, USB Host & Client, Wiegand

General Purpose I/O

4 inputs (DC 0~24V), 4 outputs (DC_MAX:30V,2A; AC_MAX:125V,0.3A), optically isolated

External WIFI / 4G, built-in Bluetooth optional

Power supply

DC 24V/2.5A (DC 9V ~ 30V, 30W)

Environmental

Operating Temp.

-20 - +70°C

Storage Temp.

-40 - +85°C

Humidity

5-90% non-condensing (+25℃)

Sealing

IP5X standard, IP65 sealing after protective casing

Applications

    Production line management
    * Intelligent sorting products


    In order to strengthen the effective monitoring of the production quantity and quality of the products, and make the unqualified products can be sorted out accurately;To reduce manual operations and improve work efficiency, you can consider connecting to the intelligent production line management system.It can correct errors in time, greatly increase the pass rate of products, and greatly improve the company's operating efficiency.

    Asset management
    * Asset and inventory checking

    The RFID asset management platform enables each asset of the enterprise to be recorded, tracked in place, fully utilized, and reasonably allocated. All assets can be deployed in a unified manner, distributed management, and centralized monitoring to achieve visual and transparent asset management and real-time and accurate financial statistics. The assets are waste of resource allocation.

    Vehicle management:
    * ETC / automatic vehicle weighing


    Electronic toll collection, ETC, through ETC can provide pass rates, prevent traffic congestion caused by tolls, and effectively curb toll evasion, toll collectors cheating for personal gains, etc., and reduce management costs. RFID intelligent vehicle weighing management, automatically records vehicle license plate number, weight information, time information, eliminates human error, prevents vehicle jams, weighing cheating, etc., and reduces economic losses.
